MZG series vibrating feeder is widely used to feed the bulk, granular and powder materials continuously, homogeneously, quantitatively into the receiving device from the storage silo or hopper. Commonly used to, coal; building material, chemicals, electric power, food, and other industries. It is advanced feeding equipment, small volume, lightweight, simple structure, easy to install and repair, low energy consumption, high efficiency, low noise, It is good to improve the working environment. It has been awarded “Outstanding New Product* by Henan provincial government.
Model | MZG-50 | MZG-70 | MZG-90 | MZG-110 | MZG-130 | MZG-150 | MZG-170 | MZG-180 | |
Installation Angle | 5-15 | 5-15 | 5-15 | 5-15 | 5-15 | 5-15 | 5-15 | 5-15 | |
Double Amplitude(mm) | 6-12 | 6-12 | 6-12 | 6-12 | 6-10 | 6-10 | 6-10 | 6-10 | |
Capacity
(t/h) |
Coal | 0-50 | 50-80 | 100-200 | 220-450 | 300-600 | 450-900 | 680-1300 | 750-1500 |
Explosion-proof motor | Model | YZS-10-6 | YZS-15-6 | YZS-20-6 | YZS-30-6 | YZS-30-6 | YZS-50-6 | YZS-50-6 | YZS-50-6 |
Power | 2*0.75 | 2*1.1 | 2*1.5 | 2*2.2 | 2*2.2 | 2*3.7 | 2*3.7 | 2*3.7 |
Model | MZG-130 | MZG-150 | MZG-170 | MZG-180 | MZG-200 | MZG-220 | MZG-250 | MZG-280 | |
Installation Angle | 5-15 | 5-15 | 5-15 | 5-15 | 5-15 | 5-15 | 5-15 | 5-15 | |
Double Amplitude(mm) | 6-12 | 6-12 | 6-12 | 6-12 | 6-10 | 6-10 | 6-10 | 6-10 | |
Capacity
(t/h) |
Coal | 400-700 | 600-1000 | 820-1350 | 820-1400 | 1100-1800 | 1300-2000 | 1600-2300 | 2100-3000 |
Explosion-proof motor | Model | YB3132S-6 | YB3132M1-6 | YB3132M1-6 | YB3132M1-6 | YB3132M-6 | YB3132M-6 | YB3132M-6 | YB3180L-6 |
Power | 2*3.0 | 2*4.0 | 2*5.5 | 2*5.5 | 2*7.5 | 2*7.5 | 2*11 | 2*15 |
